NEW 2026 REM SC 14 CNC/MSF Turn/Mill VTL
Overview
Description
REM SC 14 CNC MSF VTL (UMARO) Vertical Turning & Milling Lathe w/ C-axis & Live Tooling, FANUC 0i-TF
The SC 14 CNC/MSF is a heavy-duty single-column CNC Vertical Turning & Milling Lathe designed for high-precision turning, facing, boring and milling of large rotational workpieces in a single setup. The machine is configured per UMARO 2025 catalogue with the following options selected for this project:
▸ C-axis with live tooling for combined turning + milling + drilling operations in one clamping
▸ TIMKEN tapered crossed-roller bearing on the table — 11,000 kg load capacity (catalog option vs 6,000 kg standard pair of tapered roller bearings)
▸ Main turning drive: 45 kW (custom intermediate config) — between catalog standard 39 kW and optional 51-60 kW
▸ RAM section 220 × 220 mm (custom configuration) — custom configuration (UMARO catalog standard is 225 × 225 mm)
▸ FANUC 0i-TF Plus CNC with FANUC AC servomotors on all axes — open architecture, worldwide service network
▸ Automatic Tool Changer 12 stations ISO 50 (UMARO catalog standard, expandable to 16 or 26 stations)
▸ Cast iron bed and column construction with hardened/ground guideways and TURCITE-B coating
Specifications
| Table Dia | 47.2" | 1,198.9 mm |
|---|---|---|
| Swing | 55.1" | 1,399.5 mm |
| Work Ht-U/R | 39.3" | 998.22 mm |
| Power | 60 hp | 44.7 kW |
| RPM | 250 RPM | 250 RPM |
| Control | CNC (FANUC 0i-TF Plus) | CNC (FANUC 0i-TF Plus) |
| Dimensions | 177.7" x 165.3" x 216.5" | 177.7" x 165.3" x 216.5" |
| Weight | 39,680 lbs | 39,680 lbs |
Configuration Single column with cross-rail
Max. swing diameter (Ø) 1,400 mm (55.1 in)
Max. height under cross-rail — STANDARD 1,250 mm (
Max. machining height — STANDARD 1,000 mm
Table diameter (Ø) 1,200 mm (47.2 in)
LOAD CAPACITY
Crossed roller bearing — TIMKEN 9,000 daN (24,250 lb)
TABLE SPEED & C-AXIS
Table speed range — standard 2 – 250 RPM
Table slow feed (C-axis) 0.01 – 4 rpm
Table max. torque 23,850 Nm up to 18 RPM
MAIN DRIVE MOTOR
Catalog standard 45 kW
VERTICAL RAM (Z-AXIS) — RIGHT TURNING-MILLING HEAD
Vertical travel — standard 1,000 mm
RAM section — UMARO catalog standard 225 × 225 mm
FEEDS
Cutting feed X/Z axes (infinitely variable 1 – 6,000 mm/min
Rapid feed X/Z axes 1 – 10,000 mm/min
LIVE MILLING SPINDLE (C-axis)
Tool taper / cone HSK A100/6,000 daN tool clamping force
Spindle speed — standard 2,000 RPM
AC drive motor — this offer 22 kW
AUTOMATIC TOOL CHANGER
Number of stations — 12 – Station disc design HSK A100
Tool shank type HSK A100
CNC SYSTEM FANUC 0i-TF Plus
Servomotors & drives FANUC AC servomotors and spindle drives
Controlled axes X, Z, C (live tooling) 3
OVERALL DIMENSIONS & WEIGHT
L x W × H 4,500 × 4,200 × 5,500 mm
Total machine weight ~ 18 tons (39,680 lb)
Equipped With
▸ CNC Vertical Turning & Milling Lathe SC 14 CNC/MSF — main machine assembly, fully assembled and tested at REM Bacău factory (per UMARO Catalogue 2025)
▸ Table Ø 1,200 mm with TIMKEN crossed-roller bearing — heavy-duty execution, 9,000 kg load capacity
▸ Main turning drive — 45 kW (custom intermediate config) AC motor with FANUC spindle drive, 2 – 250 RPM (catalog standard)
▸ Vertical Turning-Milling right rail head — ram 225 × 225 mm (custom configuration), Z-stroke 1,000 mm (catalog standard), taper, tilting ± 30°
▸ C-axis with live tooling — milling spindle 10 – 2,000 RPM, drive motor 22 kW
▸ Automatic Tool Changer (ATC) — 12 - Station HSK A100 disc magazine, HSK A100
▸ Standard tool holders for turning
▸ Set of 4 jaws (UMARO catalog standard)
▸ Guards for table and lighting installation (REM UMARO catalog standard)
▸ FANUC 0i-TF Plus CNC system with 15" color LCD operator panel
▸ FANUC AC servomotors and spindle drives on all controlled axes (X, Z, C)
▸ Hardened and ground guideways with antiFriction coating on slides
▸ Centralized automatic lubrication system
▸ External cooling system with chip flushing and 200 L tank
▸ Hydraulic system for clamping and counterweight
▸ Operator console with ergonomic suspended pendant
▸ Full machine enclosure (CE-compliant safety guarding)
▸ Levelling blocks, foundation bolts and assembly tools
▸ Spare parts kit for 2 years of operation (mechanical wear parts)
▸ Maintenance Manual, operator manual, CNC manual, programming instruction, electrical wiring diagram, PLC program (UMARO catalog standard documentation)
▸ Tool-holders set: 6 standard ISO 50 holders for turning + 2 holders for live milling
▸ Geometric acceptance test report per ISO 3655 / ISO 230 — Renishaw XL-80 laser interferometer
