| Rect-Cap (H) | 13" | 330.2 mm |
| Rect-Cap (W) | 18" | 457.2 mm |
| Rounds-Cap | 13" | 330.2 mm |
| Square-Cap | 13" | 330.2 mm |
| Power | 3 hp | 2.2 kW |
| Blade Width | 1" | 25.4 mm |
| Blade Thickness | 0.032" | 0.8128 mm |
| Blade Length | 162" | 4,114.8 mm |
| Dimensions | 92 x 75 x 52 | 92 x 75 x 52 |
| Weight | 2500 lbs | 2500 lbs |
Specifications (subject to buyer verification):
Capacity 90°: Rectangular: 13” x 18”, Round: 13”
Capacity 45°: Rectangular: 13” x 10 3/4”, Round: 12”
Capacity 30°: Rectangular: 13” x 7 3/4”, Round: 8 1/2”
Blade Size: 1” x 14’ 10”
Blade Drive: 3 HP VFD
Blade Speed: 45 - 330 SFM
Table Height: 31"
Coolant Tank Capacity: 6 Gallons
Workload: 5,000 lbs
Machine Voltage: 208*, 240*, 480, 575* v *Transformer supplied at no charge
Machine Weight: 2,500 lbs.
Dimensions (W x L x H): 92” x 75” x 52”
