| X | 47.24" | 1,199.9 mm |
| Y | 25.59" | 649.99 mm |
| Z | 19.69" | 500.13 mm |
| Table Size-W | 39.37" | 1,000 mm |
| Table Size-L | 62.99" | 1,599.9 mm |
| Worktank Inside Dimensions | 82.6 x 49.2 x 25.6" | 82.6 x 49.2 x 25.6" |
| Max. Workpiece Weight | 11023 Lbs. | 11023 Lbs. |
| C-axis | Yes | Yes |
| Tool Changer | Yes | Yes |
| # of Stations | 6 | 6 |
| Control Type | Sodick LN20 | Sodick LN20 |
| Screen Size | 15 | 15 |
| Program Input Methods | Keyboard, USB, Ethernet | Keyboard, USB, Ethernet |
| Power Pack | 160 mA | 160 mA |
| Tooling Available for Purchase | Yes | Yes |
- LN20 Control (Controls up to 8 Axes)
- MMK MDEi401 Rotary Table (integrated into control)
- SEC10 C-axis
