USED Parker 33753-SS 12M10-1FSD

🔧 General Specifications
Model: 33753-SS 12M10-1FSD
Model: 33753-SS 12M10-1FSD
Series: Parker 12S (high-pressure inline filters)
Series: Parker 12S (high-pressure inline filters)
Filter Element Rating: 10 microns (based on the “10” in the part number)
Filter Element Rating: 10 microns (based on the “10” in the part number)
Temperature Range: –20 °F to 100 °F
Temperature Range: –20 °F to 100 °F
Operating Pressure: Rated for use at 120 PSI (actual housing is capable of much higher pressures—often up to 6000 PSI burst pressure)
Operating Pressure: Rated for use at 120 PSI (actual housing is capable of much higher pressures—often up to 6000 PSI burst pressure)
Material: 316 stainless steel (indicated by “SS”)
Material: 316 stainless steel (indicated by “SS”)
Seal Material: Fluorocarbon (Viton) — indicated by “FSD”
Seal Material: Fluorocarbon (Viton) — indicated by “FSD”
Connections: Typically inline male NPT (often ¾″ NPT)
Connections: Typically inline male NPT (often ¾″ NPT)
⚙️ Functional Highlights
Designed for inline filtration of high-pressure hydraulic or process fluids.
Designed for inline filtration of high-pressure hydraulic or process fluids.
Suitable for use with mineral oils, petroleum-based fluids, and many synthetic lubricants.
Suitable for use with mineral oils, petroleum-based fluids, and many synthetic lubricants.
Compatible with low-temperature environments down to –20 °F.
Compatible with low-temperature environments down to –20 °F.
Provides fine filtration to protect sensitive downstream components in fluid systems.
Provides fine filtration to protect sensitive downstream components in fluid systems.
The stainless steel body ensures high corrosion resistance, suitable for outdoor or demanding industrial environments.
The stainless steel body ensures high corrosion resistance, suitable for outdoor or demanding industrial environments.
🧩 Common Applications
Hydraulic power units (HPUs)
Hydraulic power units (HPUs)
Instrumentation and test stands
Instrumentation and test stands
Process control systems
Process control systems
Offshore or cold-climate equipment
Offshore or cold-climate equipment
Industrial fluid handling systems
Industrial fluid handling systems

Weight: 43 lbs
Dimensions: 20 × 14 × 10 in
