UD100356: Heckert FU-400 x 1600 APUG

Specifications:

Working surface: 16-1/4" x 63"
Number of t-slots: 5
Width of t-slots: 11/16"
Distance between t-slots: 2-1/2"
Maximum weight of workpiece: 3,300 Lbs

Travels:
Longitudinal travel: 44"
Cross travel: 14"
Vertical travel: 21-3/4"
Horizontal spindle:
Spindle drive: 15 HP
Spindle taper: #50
Diameter of front bearing: 4-5/16"
Number of spindle speeds: 18
Range of spindle speeds : 45 - 2240 RPM
Spindle center to table surface - maximum : 23-3/4"
Spindle center to table surface - minimum : 2"
Spindle center to overarm support: 6-5/16"
Motorized vertical over arm:
Spindle drive: 15 HP
Spindle taper: 50
Diameter of front bearing: 4-5/16"
Number of spindle speeds: 18
Range of spindle speeds: 28 to 1400 RPM
Spindle nose to table surface - maximum: 32-7/8"
Spindle nose to table surface - minimum: 8"
Spindle center to column ways - maximum: 48"
Spindle center to column ways - minimum: 14"

Feeds:
Feed drive: 3 HP
Number of feeds: 18
Range - longitudinal & cross - per min.: .63" - 31.5"
Range - vertical - per min.: .20" - 10"
Rapid travel - longitudinal & cross: 124" Per min.
Rapid travel - vertical: 40" Per min.
Coolant system:
Pump drive: 1/8 HP
Delivery rate: 2.6 Gal. Per min.
Sump capacity: 12 Gallons
Electrical:
Connected load:: 31.8 KVA
Amp load: 55

Dimensions & weight:
Net weight: 8,600 Lbs
Required floor space - W x D x H: 138"W x 139"D x 81"H
