UD100192: Iemca Master 880/38F

Specifications:
Bar size capacity, round: 5/16" - 3 1/8"
Bar size capacity, Hex: 9/32" - 2 11/16"
Bar length capacity: 12'
Magazine capacity bundle : 5,000 lbs
Max. feed speed: 29.5" Per Second
Return speed: 29.5" Per Second
Bar change time : 35 Seconds
Oil specifications guide channel : ISO 150 (not included)
Oil capacity : 40 Liters (15 gal)
Compressed air: 90 PSI
Total power required : 2 KW
Operating voltage : 230 V/3/60
Control voltage: 24 VDC
Machine : 175" x 47" x 59"
Weight (approx): 4,000 LBS

Equipped With:
Bundle loader
Automatic remnant retraction
LL pusher Length
Double pusher design (space saving design)
Quick change over guide channel sets
(1) 26mm guide channel set with nose
