NEW HYUNDAI WIA SE2600LY
Overview
Description
OverviewThe SE2600Y/SY series feature a 30 degree slant bed design which was developed using finite element analysis (FEA) to absorb vibration and minimize thermal growth, ensures a stable platform for powerful precise cutting capabilities. Roller guide ways adopted X, Y and Z axis offer improved rigidity due to the increase surface contact with the guideway, and can applicable for a variety of applications. HYUNDAI WIA's advanced technological features to provide exceptional value.
Specifications
Hyundai Wia FANUC Smart Plus controller
FANUC Beta spindle drive with Beta X and Z servo motors
Main spindle: 3,500 RPM belt-driven
Main spindle motor: 25 HP (18.5 kW), S2 15 min duty, 347.3 lb-ft (470.9 Nm) torque at 375 RPM
Main chuck: 10 in 3-jaw (sub spindle 6 in)
Main bar capacity: 3.2 in (81 mm)
Maximum turning diameter: 15.0 in (380 mm)
Maximum turning length: 24.8 in (630 mm)
BMT 55P turret with 12 stations and 24 positions
Y-axis travel: 4.3 in (110 mm)
Tool capacity: 0.75 in square turning tools, 1.5 in (40 mm) boring bars
Live tooling: 6,000 RPM (BMT 55P)
Live tool motor: 7.4 HP (5.5 kW), S2 15 min duty, 38.7 lb-ft (52.5 Nm) torque at 1,000 RPM
30 degree slant, one-piece bed structure
High-speed roller linear guideways
Rapid traverse rates: X-axis 1,181 IPM (30 m/min), Z-axis 1,181 IPM (30 m/min)
Rapid traverse rates: Y-axis 394 IPM (10 m/min), ZB-axis 591 IPM (15 m/min)
87 PSI coolant system (1,015 PSI optional)
Double pre-tensioned ball screws
Chip conveyor with 47 in discharge height
Separate coolant tank
Three-color tower signal light
Parts catcher (main spindle on SE2600Y, sub spindle on SE2600SY)
Full contouring C-axis
Max Turn Dia: 15 in.
Max Turn Len: 24.8 in.
Chuck Size: 10 in.
Spindle RPM: 3,500
Spindle HP: 25
Rapids(X): 1181
Rapids(Y): 1181
Rapids(Z): 1181
Travel(X): 8.54
Travel(Z): 31.81
