USED SMC CDQ2B25-50DM
Overview
Description
The SMC CDQ2B25-50DM is a compact pneumatic cylinder from SMC's CQ2 series featuring a 25mm bore and 50mm stroke length. This double acting, single rod cylinder is designed for space-saving applications with a compact body design and magnetic piston for auto switch mounting capabilities.
Specification
Value
Brand
SMC
Model/Part Number
CDQ2B25-50DM
Series
CQ2
Type
Pneumatic Cylinder
Cylinder Action
Double Acting
Bore Diameter
25mm
Stroke Length
50mm
Mounting Style
Through-hole (Standard)
Port Thread Type
M Thread
Rod End
Male Thread
Built-in Magnet
Yes
Operating Pressure Range
0.05MPa to 1.0MPa
Proof Pressure
1.5MPa
Operating Temperature
-10°C to +70°C
Auto Switch Mounting
2 Surfaces (12-25mm bore)
We warranty all items for 30 days from date of purchase.
Specifications
| Weight | 1.00 LBS | 1.00 LBS |
|---|
SKU: AI1455
UPC: 679523686208
Condition: Used
Availability: In Stock
Weight: 1.00 LBS
Width: 7.00
(in)
Height: 6.00
(in)
Depth: 7.00
(in)
Shipping: Calculated at Checkout
GTIN: 679523686208
Manufacturer: SMC
Part Number: CDQ2B25-50DM
Shelf: K -67
Bore Diameter: 25 mm
Model: CDQ2B25-50DM
MPN: CDQ2B25-50DM
Type: Pneumatic Cylinder
