Prime power: 20 kW (25 kVA); standby: 22 kW (27.5 kVA) at 0.8 pf, 60 Hz, 1800 rpm Single‑phase: 14.4 kW prime, 15.8 kW standby (0.8 pf); three‑phase: 20 kW / 22 kW Voltage selection (three‑phase): 208Y/120, 220Y/127, 240Y/139, 416Y/240, 440Y/254, 480Y/277 Voltage (single‑phase): 120 V or 240 V via selector switch Voltage regulation: ±0.5% no load to full load; frequency regulation ±0.25% Engine: Isuzu 4LE2T, 4‑cylinder, turbocharged, EGR; EPA Tier 4 Final Displacement: 2,179 cc (133 in³); gross output: 40.2 hp (30 kW) at 1,800 rpm Fuel tank: 41.7 gal; fuel consumption: 1.62 gph at full load, 0.94 gph at half load Cooling capacity: 2.3 gal (with radiator); air‑cooled alternator Brushless, revolving‑field alternator, single bearing Excitation: AVR with open delta for high motor‑starting capability Insulation: Class F Sound level: 65 dB(A) at 23 ft Fuel type: ULSD (ASTM D975 No. 1 & 2) Exhaust temperature: 847 °F; flow: 148 cfm at full load Controller: ECU755 microprocessor Digital gauges: oil, temperature, battery, RPM, fuel Meters: analog AC ammeter/voltmeter, frequency meter Switches: breaker, selector switches, AVR adjuster Protections: auto shutdown (temperature, oil pressure, overspeed, overcrank); emergency stop Enclosure: sound‑attenuated steel with e-coat and powder coat; integrated spill containment (124%) Operating range: −40 °F to 185 °F Fan power draw: 0.67 hp Three‑phase output: 60 A @ 208–240 V; 30 A @ 480 V Single‑phase output: 60 A @ 120 V; 60 A @ 240 V Main breaker: 60 A; trip current: 30 A
| Weight | 2137.0 | 2137.0 |
Status: Available
Weight: 2137.0
Rental Rate: $999
Rate Schedule: DAY: $150
Rate Schedule: WEEK: $330
Rate Schedule: 3 MOS: $2997
Rate Schedule: 6 MOS: $5994
