Reading Direction:
Front
Scanning Method:
Single
Light Source:
Visible Semiconductor Laser (wavelength: 600 nm)
Control Output:
85 ë_W
Pulse Duration:
112 ë_s
Laser Class:
Class 2 Laser Product
Supported Codes:
CODE39, ITF, industrial2of5, COOP2of5, CODABAR, CODE 128, GSI-128, CODE93, UPC/EAN, GS1 Databar
Number of Readable Digits:
74 Digits (148 digits for CODE128 with start character C)
Readable Bar Width:
0.125mm
Reading Distance:
65 to 500mm (narrow bar width: 1.0mm)
Focal Point:
120mm
Largest Readable Label Width:
339mm (distance: 350mm, narrow bar width: 1.0mm)
PCS:
0.4 or more
Scanning Rate:
500-1300 scans/sec
Number of Inputs:
2 (IN1 and IN2)
Input Format:
No-Voltage Input
Number of Outputs:
4 (OUT1, OUT2, OUT3, and OUT4)
Output:
NPN open collector
Rated Load:
24V DC, 30 mA
Leakage Current:
0.1 mA or less
Residual Voltage:
0.5V or less
Communication Method:
Conforms to EIA RS-232C
Communication Speed:
600, 1,200, 2,400, 4,800, 9,600, 19,200, 31,250, 38,400, 57,600, 115,200 bps
Synchronization between the transmitter and receiver: Asynchronous
Data Bit Length:
7 or 8 bits
Stop Bit Length:
1 bit or 2 bits
Parity Check:
None, odd, even
Operating Voltage:
5V DC +/- 5%
Voltage Consumption:
400mA or Less
| Weight | 5.00 LBS | 5.00 LBS |
SKU: IP5171
UPC: 641752899032
Condition: Used
Availability: In Stock
Weight: 5.00 LBS
Width: 12.00
(in)
Height: 8.00
(in)
Depth: 12.00
(in)
Shipping: Calculated at Checkout
Type: Digital Barcode Laser Scanner
MPN: BL-1300
Model: BL-1300
Shelf: D-3 Tub 1
Series: BL
Range: 65 - 500mm
Manufacturer: Keyence
Country/Region of Manufacture: Japan
GTIN: 641752899032
