STANDARD EQUIPMENT & ACCESSORIES
• Main Motor: 20 HP, 230V / 460V, 3 Phase, 60
Cycle, Switch and Wiring Complete
• 4.09” Spindle Bore
• Spindle Nose: D1-11 Camlock
• Headstock Spindle Adapter ASA#450 to MT#6
• Chuck Guard
• Set of Change Gears for Special Leads
• Hardened and Ground Bedways
• Tool Slide with T-Slot
• 4-Way Rapid Traverse
• Thread Chasing Dial
• Tailstock Safety Locking Chock
• 2-Speed Drive Tailstock Quill
• Coolant System with Pump and Piping
• Pull Drawer Chip (Coolant) Pan
• UL Electrical Components & Cables
• Tool Box with Necessary Wrenches & Spanners
• Instruction Manual and Parts List
Swing over Bed: 30" 34" and 40"
Swing in Gap: 41", 45" and 51.5"
Bed Length: 80" 120",160",200",240",280" and 320"
Swing over Crosslide: 20.7", 25.1" and 31"
Spindle Bore: 4.07"
Spindle Mount: D1,11
Spindle speeds: 8-800 RPM
Motor HP: 20 HP
