| X Axis Travel | 57.1" | 1,450.3 mm |
| Y Axis Travel | 47.2" | 1,198.9 mm |
| Z Axis Travel | 51.9" | 1,318.3 mm |
| B Axis | 160° | 160° |
| Spindle Motor | 161 hp | 120.1 kW |
| Spindle Speed | 30,000 RPM | 30,000 RPM |
| ATC Capacity | 120 | 120 |
| Spindle Taper | HSK-A63/80 | HSK-A63/80 |
| Table Size | 31.49" x 31.49" | 31.49" x 31.49" |
| Max Load | 4,409 lb | 1,999.9 kg |
| Dimensions | 393.7” x 255.9” x 177.1” | 393.7” x 255.9” x 177.1” |
| Weight | 66,138 Lbs | 66,138 Lbs |
Siemens 840D Solution Line CNC Control
Liebherr PHS 1500-H 22 station FMS
16 Pallets
Laser Tool Measuring
Full Machine Enclosure
50 Bar External Flood & Through the Tool Coolant Pressure
