Base to Bore Centerline: 3-3/4 in
Base Width: 2.94 in
Bolt Center-to-Center Length: 9.88 to 11.5 in
Bore Diameter: 3 in
Bore Type: Round
Expansion Type: Non-Expansion Bearing (Fixed)
Finish: Black Oxide
Load Capacity: 11120 lb Dynamic/61200 lb Static
Locking Device: 65 deg Setscrew
Material: Cast Iron
Maximum Speed: 2060 rpm
Mounting Type: Two Bolt Base
Overall Height: 7.92 in
Overall Length: 13.44 in
Overall Width: 4-1/2 in
Seal Type: Trident&trade
Seal Type: Triple Lip
