| X | 31.5" | 800.1 mm |
| Y | 23.6" | 599.44 mm |
| Z | 19.7" | 500.38 mm |
| Dimensions | 51.2" x 40.9" x 19.7" | 51.2" x 40.9" x 19.7" |
| Weight | 11,000 lbs | 11,000 lbs |
Specifications (subject to buyer verification):
X-axis travel: 31.5"
Y-axis travel: 23.6"
Z-axis travel: 19.7" - 31.5"
Maximum workpiece dimensions: 51.2" x 40.9" x x19.7"
Allowable weight on table: 11,000 lbs
U/V-axes travel: 19.7" x 19.7"
Maximum angle of conical cut (optionally ±45º): +/- 30º / 15.8"
Wire diameter range: 0.008" - 0.013"
Maximum cutting speed: 42"/hr – Ø 0.013" (Xcc wire)
