Work load supported 2 steady 25.000 Kg
Work load not supported 16000 Kg
incl. 4 Chuck 1600 mm
incl. 2 x Steady rest
incl. internal grinding attachment
incl. external grinding attachment
incl. milling saddle support
| Swing | 1,600 mm | 62.992" |
| Spindle Bore | 105 mm | 4.1339" |
| Power | 55 kW | 73.8 hp |
| RPM | 224 RPM | 224 RPM |
| Swing Over Cross Slide | 1,250 mm | 49.213" |
| Dimensions | 13210 x 2420 x 2400 mm | 13210 x 2420 x 2400 mm |
| Weight | 33000 kg | 33000 kg |
DBC Turning Length: 8000 mm
Swing over bed Ø: 1600 mm
Swing over cross slide Ø: 1250 mm
Spindle bore: 105 mm
Spindle power: 55 kW
Bed width: 1100 mm
Tailstock spindle Ø: 220 Ø
Stroke pinole: 600 mm
Spindle taper: Metric 80 Mk
Speeds / ranges: 224 Rpm
Feed rate X-Axis: 5000 mm/min.
Feed rate Z-Axis: 5000 mm/min.
Workpiece load: 25000
Length: 13210 mm
Width: 2420 mm
Height: 2400 mm
Weight: 33000 kg
Work load supported 2 steady 25.000 Kg
Work load not supported 16000 Kg
incl. 4 Chuck 1600 mm
incl. 2 x Steady rest
incl. internal grinding attachment
incl. external grinding attachment
incl. milling saddle support
DBC Turning Length: 8000mm
Swing over bed Ø: 1600mm
Swing over cross slide Ø:1250mm
Spindle bore: 105mm
Spindle power: 55kW
Bed width: 1100mm
Tailstock spindle Ø: 220Ø
Stroke pinole: 600mm
Spindle taper: Metric 80Mk
Speeds / ranges: 224Rpm
Feed rate X-Axis: 5000mm/min.
Feed rate Z-Axis: 5000mm/min.
Workpiece load: 25000
Length: 13210mm
Width: 2420mm
Height: 2400mm
Weight: 33000kg
