SERIAL .............................. 34828
MODEL ............................... M1L-34828
SIZE ................................ 20" X 84"
SWING OVER BED ...................... 20"
SWING OVER CROSS .................... 13"
SPINDLE HOLE BORE ................... 2"
SPINDLE SPEEDS ...................... (12) 40 TO 1800 RPM
INCH THREADS ........................ (66) 1/2 TO 152 TPI
METRIC THREADS ...................... (66) .5 TO 92 MM
CHUCK ............................... 10" 3 JAW
COMPOUND SLIDE TRAVEL ............... 5"
CROSS SLIDE TRAVEL................... 13"
TAILSTOCK SPINDLE TRAVEL ............ 5"
WIDTH OF BED ........................ 13.5"
MOTOR ............................... 7.5 KW
Brand
MEUSER
Type
Lathes, Engine
Stock No.
25402
